Model |
RH– 72 |
|
Overall Diameter |
13.00 mm |
|
Optic Diameter |
6.00 mm |
|
Haptic Angulation |
0 degree |
|
A Constant |
118.50 |
|
AC Depth |
5.20 |
|
Positioning Holes |
No |
|
Fixation Holes |
No |
|
Optic Design |
Aspheric |
|
Haptic Design |
Modified C Loop |
|
IOL Type |
Monofocal; One Piece Intraocular Lens |
|
Implantation Site |
Posterior Chamber |
|
Material |
Clear Hydrophobic Acrylic (Methacrylate Copolymer) |
|
Power Availability |
0.0D to +8.0 D (increment 1.0) +8.0D to +25.0 D (increment 0.5) +26.0D to +30.0 D (increment 1.0) +31.0D to +34.0 D (increment 1.0) Note *) custom made order. It is recommended to use a bigger cartridge size for smooth delivery. |
|
Center Thickness |
0.35 to 1.10 mm |
|
Refractive Index material |
1.54 |
|
ABBE Number |
43 |
